Sleeving machines

Sleeving machine SetLine

Easy processing of single cups, cup sets or bottles of any size and shape with the A+F SetLine. You would like to connect the packaging plant to your filling line? Create an integrated complete line that offers you maximum packaging flexibility and vast cost savings. Whether packed in a tray, a case or in a full sleeve for presentation– with the A+F SetLine you can create the exact packaging your product needs.

By the way: Thanks to the modular system concept you can adapt the cup sleeving system to your specific applications as required, process individual products or sets in defined pack formats – and optimise your processes cost-effectively thanks to short setup and changeover times.

Sleeving machine SetLine in detail

Benefits

The modular plant concept allows the configuration to be adapted to customer-specific applications
Line concepts with significant advantages in overall efficiency
The integration of several packaging steps in one line allows compact configurations with reduced space requirements
Filling and sealing of the presentation sleeve is done from above. This is associated with cost advantages due to smaller sleeve blanks as well as particularly stable, form-fitting sleeves for the optimum presentation of your products
The SetLine allows flexible processing of individual products or sets in defined pack formats - with short set-up/changeover times
The high-quality, stable construction ensures a long service life with low maintenance requirements

Technical data

Product:
FS Cups: 68 - 95 mm
FFS Cups: sets of 2, 4, 6, 8, single cups
Bottles: 40 -60 mm
Capacity:
FS cups: 40,000 cups/h
FFS cups: 43,000 cups/h
Bottles: 30,000 bottles/h
Number of layers:
FS cups: 1 and 2-ply
FFS cups: 1 and 2-ply
Bottles: 1-ply
max. height:
FS Cups: 140 mm
FFS Cups: 140 mm
Bottles: 140 mm
Cuff design:
FS cups: full cuff / clip
FFS cups: full cuff
Bottles: Full cuff / Head cuff
Tray feed / fabrication:
FS Cups: Integrated or separate
FFS Cups: Integrated or separate
Bottles: Integrated or separate
Control:
FS Cups: Schneider Electric / Allen Bradley
FFS Cups: Schneider Electric / Allen Bradley
Bottles: Schneider Electric / Allen Bradley

Applications

Sleeving of cups and bottles to form multi-packs
Inserting single cups and bottles into trays or perforated trays
Inserting multi-packs into trays
Repacking of products
Application of slip-on lids
Containers: open trays, perforated trays and trays with lids

Options

Wide range of options and special solutions to cover specific customer requirements
Integration of the line into a central carton supply or the direct integration of erectors
Additional requirements, for example the integration of labelling, inspection or reading systems, intelligent palletising or other downstream equipment can be taken into account
Efficient processing of required formats with minimum changeover time due to variable configuration
